▶ EngineEngine Manufacturer Kubota Yanmar Engine Model D902 3TNV80F-CJT Engine Type Liquid-cooled, 4-cycle diesel 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 54.8 in³ 77.3 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 21.6 hp 23.9 hp PTO Power 17.7 hp 18 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry element Dry with safety element Fuel System Direct injection Indirect injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Open center tandem pump gear type Gear Implement Flow 5.2 gpm 3.5 gpm Steering Flow 1.0 gpm 3.5 gpm Total Hydraulic Flow 6.2 gpm 7 gpm Overall Hydraulic Pump Flow 6.2 gpm 6.3 gpm Hydraulic System Type Open center tandem pump gear type Open center Rear Remote Hydraulic Flow Not Published 3.5 gpm implement circuit; total 7 gpm No. of Standard Remote Valves None (2-valve rear remote coupler optional) Not Published No. of Optional Remote Valves 2 (optional; ISO 7241-1 series A or B) Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.3 gal Coolant Capacity 3.3 qt 3.9 qt Crankcase Capacity 3.4 qt 2.9 qt Transmission / Hydraulic System Capacity 2.98 gal 3.25 gal Front Axle Fluid Capacity 3.8 qt 3.0 qt ▶ PTO & HitchPTO Type Live independent PTO (with hydraulic clutch) Independent PTO Rear STD 540 rpm 540 rpm Mid-PTO Availability USA No.5 (KUBOTA 10-tooth) involute spline, 2500 rpm Standard, 2100 rpm Category, 3-Point Hitch SAE Category I (optional) Limited Category I Hitch Lift Capacity 1,213 lb 1,177 lb Hitch Lift Capacity (at 24”) 680 lb 758 lb Lift Control Type Quarter-inching valve Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission, high-low gear shift (2 forward, 2 reverse) Hydrostatic - 2 range No. of Speeds 2 Range (Low-High) Infinite (hydrostatic), 2 ranges forward and reverse Max Travel Speed (Forward) 0 mph to 8.4 mph 9.1 mph Max Travel Speed (Reverse) 0 mph to 6.5 mph 9.1 mph Clutch Dry type single plate - Main clutch 9.45" wet disc Differential Lock & Limited Slip Options Rear differential lock standard Standard rear differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS Semi-flat platform; two-post folding ROPS; four-wheel drive Steering Hydrostatic Power Steering Power steering Brakes Mechanical, wet disc type Wet disk, left-hand pedal Seat Suspension & Adjustability High-back reversible seat (rotates for backhoe operation); fore/aft slide and backrest tilt adjustment Deluxe suspension seat with armrests and tilt steering wheel Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing 4WD (MFWD), on-the-go engagement Front Axle Rating Not Published 1,349 lb Drawbar Capacity Maximum tongue weight 550 lb 2,165 lb ▶ Dimensions & ManeuverabilityOverall Width 45.1 in 47.22 in (R3 tires); 47.32 in (R4 tires) Wheelbase 55.1 in 57.1 in Ground Clearance 6.5 in (front axle) 7.7 in (front axle) Min. Turn Radius without Brakes 7.5 ft 7.4 ft (no brakes, no MFWD) Height to Top of ROPS 86.2 in 90 in (ROPS extended, R4 tires) Height to Top of ROPS (folded) Not Published 73 in Height to Top of Cab Model Not Published Not Published Overall Length 99.0 in (with 3-point hitch, with front guard) 108 in ▶ WeightTractor Weight (Base) 1,600 lb (with ROPS, front guard and control valve assembly) 1,556 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front Turf/Industrial: 18×8.5-10; Rear Turf/Industrial: 26×12-12; Bar tire N/A Standard R4, optional R3 R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 18×8.5-10 18x8.5-10 R3 Turf - Rear 26×12-12 26x12-12 R4 Industrial - Front 18×8.5-10 18x8.5-10 R4 Industrial - Rear 26×12-12 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System Kubota Swift-Tach (Quick attach) Tool-free attach and park (MSL optional on 120R) Loader Model LA340S (standard, quick attach); LA340 (pin-on option) 120R (MSL or NSL); 120E (NSL only) Loader Lift Height 71.0 in (at pivot pin) 120R: 72 in; 120E: 71.2 in Loader Lift Capacity (Full Height) 739 lb (LA340 pin-on); 613 lb (LA340S quick attach) 120R (MSL): 680 lb; 120E (NSL): 519 lb (at 19.7 in ahead of pivot) Loader Breakout Force 1,407 lbf (LA340 pin-on); 1,286 lbf (LA340S quick attach) Not Published ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours Powertrain 6 years, standard at no cost, covers residential and commercial use ▶ ITC Company AccessoriesAccessories that fit None tagged yet
