▶ EnginePTO Power 15 hp 15.4 hp Alternator 40 A, 12 V 40 A, 12 V Air Cleaner Replaceable paper elements Single Dry Engine Type 3-cylinder, Indirect-injection, Water-cooled Natural Aspiration Fuel System Mechanical, in-line type Diesel Displacement 68 in³ 60.6 (993) No. of Cylinders 3 3 Rated Engine Speed 3000 rpm 3,200 Cooling System Type Water-cooled Water cooled Engine Manufacturer Yanmar Yanmar Engine Power (Gross) 21.5 hp 21.5 hp Engine Emissions Constraints Tier 4 Tier 4 ▶ WeightTractor Weight (Base) 1,433 lbs 1,433 (650) Weight with ROPS and Loader Not Published 1,433 lb Weight with Cab and Loader Not Applicable Not Published ▶ WarrantyWarranty Length & Coverage 6 Year Limited Warranty 7-year powertrain warranty ▶ HydraulicsPump Type Gear Single Gear Pump with Flow Divider Steering Flow 2.1 gpm 2.11 gpm Implement Flow 4.6 gpm 4.17 (15.8) Total Hydraulic Flow 6.7 gpm 6.97 (26.4) Hydraulic System Type Open center system, Position control Not Published System Operating Pressure 1,885.5 psi n/a Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 6.7 gpm 6.97 gpm (max total flow) No. of Optional Remote Valves 1 Up to 1 No. of Standard Remote Valves 0 Not Published ▶ PTO & HitchPTO Rear Standard (540 rpm) 540 rpm PTO Type Independent Independent Lift Control Type Position Position Hitch Lift Capacity 970 lbs. (At 24 in: 728) 1,100 lb Mid-PTO Availability Standard (2,500 rpm) Optional (2,500 rpm) Category, 3-Point Hitch CAT I Category I (N) Hitch Lift Capacity (at 24”) 728 lb 679 lb ▶ Tire OptionsR3 Turf - Rear 26 x 12.0 - 12 TURF R 16X12.00-12 R3 Turf - Front 18 x 8.5 - 10 TURF F 16X7.50-8 Tire Size & Options Front: 18x8.5-10 Industrial; Rear: 26x12.0-12 Industrial R1 (BAR) / R3 (TURF) / R4 (IND) R4 Industrial - Rear 26 x 12.0 - 12 26X12-12 R4 Industrial - Front 18 x 8.5 - 10 18X8.50-10 R1 Agricultural - Rear Not Published BAR R 24X12.00-12 R1 Agricultural - Front Not Published BAR F 16X7.50-9 ▶ Fluid CapacityCoolant Capacity 0.9 gal (0.9U.S.gals) 0.9 gal Crankcase Capacity 0.8 gal (0.8U.S.gals) 0.48 gal Fuel Tank Capacity 6.6 gal. 6.6 gal Front Axle Fluid Capacity 0.5 gal (0.5U.S.gals) 2.6 qt Transmission / Hydraulic System Capacity 3 gal (3.0U.S.gals) 3.6 gal ▶ Loader & AttachmentsLoader Lift Height 72.0 in. 72.7 in (under level bucket); 78.5 in (pivot pin) Loader Breakout Force 1,960 lbs. 1,531 lb (at pivot pin, ground level) Quick Attach Loader System LL1101: Pin-Type Bucket (standard); Quick Attach Assembly (Optional) - Compact Type (dual-lever LH/RH); LL1700: Quick Attach Implement System SSQA Loader Lift Capacity (Full Height) 1,007 lbs. 992 lb (at pivot pin) ▶ Transmission & DrivetrainClutch Not Applicable Dry single plate No. of Speeds 2 Ranges 2 Range Transmission Type Hydrostatic Drive Hydrostatic transmission (HST) Max Travel Speed (Forward) 0 ~ 14.0 Km/h (0 ~ 8.70 mph) 7.8 mph Max Travel Speed (Reverse) 0 ~ 8.4 Km/h (0 ~ 5.22 mph) Not Published Differential Lock & Limited Slip Options Mechanical pedal type Mechanical rear differential lock ▶ Chassis, Steering & ControlsBrakes Wet, Multi-disc Wet disc Steering Hydrostatic Power Steering Hydrostatic Frame Type Not Published Sub-compact tractor, 4WD Front Axle Type Front Wheel Mechanical Assist (4WD) Center pin front axle Drawbar Capacity Vertical load: 881.8 lb (882lbs), Horizontal load: 1.6 tonnes (3527lbs) Not Published Front Axle Rating 1433 lb Not Published Seat Suspension & Adjustability High-Back Seat with Foldable Armrest and Retractable Seatbelt; fore/aft adjustable Standard adjustable seat ▶ Dimensions & ManeuverabilityWheelbase 56 in. 53.1 (1,350) Overall Width 47 in. 44.5 (1,130) Overall Length 97 in. 94.2 (2,394) Ground Clearance Not provided in source 8.3 in. Height to Top of ROPS 87 in. 86.6 (2,200) Height to Top of Cab Model Not Applicable Not Published Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes 7.87 ft 86.6 (2,200) Overall Length with 3-Point Hitch 97 in. 94.2 in
