▶ EnginePTO Power 28 hp 28.3 hp Alternator 70 A, 12 V 50 A, 12 V Air Cleaner Dry Not Published Engine Type 4-stroke, vertical, water cooling, CRDI 4-cycle, liquid-cooled, diesel Fuel System Delphi, CRDI Not Published Displacement 114.7 in³ 100.5 in³ No. of Cylinders 3 3 Rated Engine Speed 2600 rpm 2700 rpm Cooling System Type Water-cooled Liquid-cooled Engine Manufacturer LS Mtron KIOTI (Daedong) Engine Power (Gross) 35 hp 35 hp Engine Emissions Constraints Tier 4 Not Published ▶ WeightWeight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Applicable Not Published ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor ▶ HydraulicsPump Type Gear pump, engine drive Not Published Steering Flow 5.5 gpm 4.7 gpm Implement Flow 7.8 gpm 7.8 gpm Total Hydraulic Flow 13.3 gpm 12.5 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 13.3 gpm 12.5 gpm No. of Optional Remote Valves Not Published 1 No. of Standard Remote Valves 2 Pair 0 ▶ PTO & HitchPTO Rear 540 rpm 540 rpm PTO Type Independent PTO with wet disk clutch Independent Lift Control Type Position & Draft Position and draft control Hitch Lift Capacity 1,808 lbs 2,270 lb (listed as “at ends”) Mid-PTO Availability Option (2,000 rpm) Optional (2000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity (at 24”) 1,433 lbs 2,425 lb ▶ Tire OptionsR3 Turf - Rear 41X14-20 41X14-20 R3 Turf - Front 25X8.5-14 27X8.50-15 Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear 43X16-20 14.9X24 R4 Industrial - Front 25X8.5-14 10X16.5 R1 Agricultural - Rear 11.2-24 12.4-24 R1 Agricultural - Front 7.0-14 7-16 ▶ Fluid CapacityCoolant Capacity 1.9 gal Not Published Crankcase Capacity 1.5 gal Not Published Fuel Tank Capacity 10.6 gal 11.5 gal Front Axle Fluid Capacity 1.7 gal 10 qt Transmission / Hydraulic System Capacity 7.9 gal 7.8 gal ▶ Loader & AttachmentsLoader Lift Height 94.4 in Not Published Loader Breakout Force 3,612 lbs Not Published Quick Attach Loader System LL3116: Standard Skid Steer Coupler (skid-steer compatible quick-attach) Not Published Loader Lift Capacity (Full Height) 2,185 lbs Not Published ▶ Transmission & DrivetrainClutch Not Applicable Not Published No. of Speeds 2 Pedal with 3 Range - HST 8F/8R Transmission Type Hydrostatic Drive Synchronized shuttle Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Not Published ▶ Chassis, Steering & ControlsBrakes Wet, Multi-disc Wet disc Steering Hydrostatic Power Steering Hydrostatic power steering Frame Type Not Published 4x4 MFWD 4WD Front Axle Type Not Published 4WD (MFWD) Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 69.1 in 65.7 in Overall Width 59.3 in 57.1 in Ground Clearance Not Published 11.4 in Height to Top of ROPS 94.0 in 92.5 in Height to Top of Cab Model Not Applicable Not Published Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Overall Length with 3-Point Hitch 136.1 in 126.3 in ▶ ITC Company AccessoriesAccessories that fit None tagged yet
