▶ EnginePTO Power n/a 44 hp Alternator n/a 70 A, 12 V Air Cleaner n/a Not Published Engine Type n/a Water-cooled, 4-stroke common rail turbocharged diesel Fuel System n/a High pressure common rail (ECU controlled) Displacement n/a 0.1 in³ No. of Cylinders n/a 3 Rated Engine Speed n/a 2600 rpm Cooling System Type n/a Pressurized liquid w/ recirculating bypass Engine Manufacturer n/a LS Mtron Engine Power (Gross) n/a 57.8 hp @ 600 rpm Engine Emissions Constraints n/a Tier 4B Final ▶ WeightWeight with ROPS and Loader n/a Not Published Weight with Cab and Loader n/a Not Published ▶ WarrantyWarranty Length & Coverage n/a 6-year limited powertrain, 2-year full coverage ▶ HydraulicsPump Type n/a Gear Steering Flow n/a HST: 6.3 gpm; Gear: 4.2 gpm Implement Flow n/a 8.5 gpm Total Hydraulic Flow n/a HST: 14.8 gpm; Gear: 12.7 gpm Hydraulic System Type n/a Open center Rear Remote Hydraulic Flow n/a Not Published Overall Hydraulic Pump Flow n/a HST: 14.8 gpm; Gear: 12.7 gpm No. of Optional Remote Valves n/a 1 No. of Standard Remote Valves n/a 1 ▶ PTO & HitchPTO Rear n/a 540 rpm PTO Type n/a Independent, electro-hydraulic engagement Lift Control Type n/a Position control Hitch Lift Capacity n/a 2,756 lb Mid-PTO Availability n/a Optional Category, 3-Point Hitch n/a Category I Hitch Lift Capacity (at 24”) n/a 2,469 lb ▶ Tire OptionsR3 Turf - Rear n/a 41X14.00-20 R3 Turf - Front n/a 28X8.50-15 Tire Size & Options n/a R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear n/a 17.5LX24 R4 Industrial - Front n/a 12X16.5 R1 Agricultural - Rear n/a 13.6-24 R1 Agricultural - Front n/a 9.5-16 ▶ Fluid CapacityCoolant Capacity n/a 2.3 gal Crankcase Capacity n/a 5.8 qt Fuel Tank Capacity n/a 11.0 gal Front Axle Fluid Capacity n/a 2.2 gal Transmission / Hydraulic System Capacity n/a 11.4 gal ▶ Loader & AttachmentsLoader Lift Height n/a 109 in Loader Breakout Force n/a 4,081 lb Quick Attach Loader System n/a 260TLA: New Holland Quick Mount; optional skid steer quick attach plates Loader Lift Capacity (Full Height) n/a 2,371 lb ▶ Transmission & DrivetrainClutch n/a HST: Not Applicable; Gear: Dry disc No. of Speeds n/a HST: 3-range; Gear: 16F/16R Transmission Type n/a HST: 3-range hydrostatic; Gear: 16x16 Max Travel Speed (Forward) n/a HST: 15.63 mph; Gear: 16.8 mph Max Travel Speed (Reverse) n/a HST: 11.37 mph; Gear: 15.3 mph Differential Lock & Limited Slip Options n/a Differential lock ▶ Chassis, Steering & ControlsBrakes n/a Wet disc Steering n/a Power steering Frame Type n/a Not Published Front Axle Type n/a 4WD (FWD) Drawbar Capacity n/a Short: 2,317 lb; Regular: 1,598 lb; Extend: 1,091 lb Front Axle Rating n/a Not Published Seat Suspension & Adjustability n/a Not Published ▶ Dimensions & ManeuverabilityWheelbase n/a 73 in Overall Width n/a 63 in Ground Clearance n/a 15 in Height to Top of ROPS n/a 96 in Height to Top of Cab Model n/a 91 in Height to Top of ROPS (folded) n/a Not Published Min. Turn Radius without Brakes n/a Not Published Overall Length with 3-Point Hitch n/a 142 in
