New Holland Workmaster 25 vs Kubota B2601HSD | Side-by-side comparison | ITC Resource Center
Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
Pump Type
Mechanical
Dual pump
Steering Flow
4.6 gpm
Not Published
Implement Flow
7.9 gpm
8.3 gal/min total - open center dual pump system shared between steering and implement circuits; individual split not published
Total Hydraulic Flow
12.5 gpm
8.3 gpm 31.4 lpm
Hydraulic System Type
Open center
open center
Rear Remote Hydraulic Flow
Not Published
8.3 gal/min (total system - individual remote valve flow not separately published)
Overall Hydraulic Pump Flow
12.5 gpm
8.3 gpm
No. of Optional Remote Valves
1 or 2
1 (single rear remote is optional)
No. of Standard Remote Valves
0
Not Published
PTO Rear
540 rpm
540
PTO Type
Independent, electro-hydraulic engagement
Independent
Lift Control Type
Position control
position control
Hitch Lift Capacity
1,808 lb
1808 lbs.
Mid-PTO Availability
HST: Standard; Gear: Optional
independent, 2500
Category, 3-Point Hitch
Category I
I
Hitch Lift Capacity (at 24”)
1,433 lb
1290 lb
R3 Turf - Rear
41X14.00-20
22x8.50-12
R3 Turf - Front
25X8.50-14
22x8.50-12
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
Ag (R1): 7-12 front / 11.2-16 rear; Turf (R3): 22x8.50-12 front / 22x8.50-12 rear; Industrial (R4): 23x8.50-12 front / 12-16.5 rear; also Goodyear R14 hybrid multi-purpose tire available
R4 Industrial - Rear
43X16-20
12-16.5
R4 Industrial - Front
25X8.50-14
23x8.50-12
R1 Agricultural - Rear
11.2-24
11.2-16
R1 Agricultural - Front
7.0-14
7-12
Coolant Capacity
5.2 qt
4.0 qts.
Crankcase Capacity
4.4 qt
3.3 qts.
Fuel Tank Capacity
7.4 gal
6.1 gal
Front Axle Fluid Capacity
6.9 qt
Not Published
Transmission / Hydraulic System Capacity
8.5 gal
4.0 gal
Loader Lift Height
72 in
78.5 in.
Loader Breakout Force
2,637 lb
2146 lbs.
Quick Attach Loader System
200LC: Quick Mount system; optional skid steer quick attach plates
