▶ EngineEngine Manufacturer Mitsubishi YANMAR Engine Model S3L2-W461GT 3TNV88F-EPLST Engine Type 3-cylinder, naturally aspirated, liquid-cooled diesel 3-cylinder, liquid-cooled, diesel, naturally aspirated, DI No. of Cylinders 3 3 Displacement 80.4 in³ 100.2 in³ Rated Engine Speed 2500 rpm 2400 rpm Engine Power (Gross) 24.4 hp 24.4 hp PTO Power Gear: 19.2 hp; HST: 17.1 hp 19 hp Engine Emissions Constraints Tier 4B (final) Tier 4 Cooling System Type Pressurized liquid with recirculating bypass Liquid-cooled Air Cleaner Dual element air cleaner (outer and inner element) Dry Fuel System In-line injection pump DI (direct injection) Alternator 50 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Mechanical Gear pump Implement Flow 7.9 gpm 6.1 gpm Steering Flow 4.6 gpm 4.6 gpm Total Hydraulic Flow 12.5 gpm 10.7 gpm Overall Hydraulic Pump Flow 12.5 gpm 10.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 pair No. of Optional Remote Valves 1 or 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 11.4 gal Coolant Capacity 1.3 gal Not Published Crankcase Capacity 4.4 qt Not Published Transmission / Hydraulic System Capacity 8.5 gal Not Published Front Axle Fluid Capacity 6.9 qt Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability HST: Standard; Gear: Optional (2,000 rpm) Available (option) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 1,808 lb Hitch Lift Capacity (at 24”) 1,433 lb 1,433 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Gear: 12x12 synchronized shuttle; HST: 3-range hydrostatic, dual pedal HST No. of Speeds Gear: 12F/12R; HST: 3-range 3 ranges Max Travel Speed (Forward) HST: 15.3 mph; Gear: 13.8 mph Not Published Max Travel Speed (Reverse) Gear: 13.10 mph; HST: 10.79 mph Not Published Clutch Gear: 9.4 in disc; HST: Not applicable Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type 4WD Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 54.1 in 66 in Wheelbase 65.9 in 69 in Ground Clearance 13 in Not Published Min. Turn Radius without Brakes 120 in (left turn); 129.8 in (right turn) 11.5 ft (3.5 m) Height to Top of ROPS 88.2 in Not Published Height to Top of ROPS (folded) 68.2 in Not Published Height to Top of Cab Model Not Published 90 in Overall Length 117.2 in 125 in (frame to link) ▶ WeightTractor Weight (Base) Gear: 2,434 lb; HST: 2,469 lb 3,609 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Ag, Industrial, VT and Turf; VT same size as Industrial R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 25x8.50-14 25x8.50-14 R3 Turf - Rear 41x14.00-20 41x14.00-20 R4 Industrial - Front 25x8.50-14 27x8.50-15 R4 Industrial - Rear 43x16-20 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System 200LC: tool-free quick-mount system; optional skid-steer quick-attach plates LL3002: ISO 24410 Quick Attaching Coupler Loader Model 200LC LL3002 Loader Lift Height 200LC: 94.3 in (at pivot pin) LL3002: 94.3 in Loader Lift Capacity (Full Height) 200LC: 1,600 lb (at bucket pivot pin, max height) LL3002: 1,599 lb (at pivot pin, maximum height) Loader Breakout Force 200LC: 2,637 lb (at bucket pivot pin) LL3002: 2,962 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain to 6 years or 1,500 hours total Two-year bumper to bumper; six-year limited powertrain
