▶ EngineEngine Manufacturer FPT FPT Engine Model R753 S8000 Engine Type Turbocharged 3-cylinder diesel Turbocharged 3-cylinder diesel No. of Cylinders 3 3 Displacement 136 in³ 179 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) 60 hp 54 hp PTO Power 51 hp 40 hp Engine Emissions Constraints Tier 4B Final Tier 4B Cooling System Type Not Published Not Published Air Cleaner 2-stage PowerCore dry air cleaner Fuel System Direct injection / Common rail Bosch electronic high-pressure common rail Alternator 75 A 120 A ▶ HydraulicsPump Type Dual hydraulic pumps; open center, fixed displacement gear pump Dual gear pumps Implement Flow 12 gpm 12.6 gpm Steering Flow 5.5 gpm 7.6 gpm Total Hydraulic Flow 17.5 gpm 20.2 gpm Overall Hydraulic Pump Flow 17.5 gpm 20.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 2 No. of Optional Remote Valves 2 1 ▶ Fluid CapacityFuel Tank Capacity 17.2 gal 21.7 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Fully independent, hydraulic wet clutch PTO Rear 540 rpm (540E optional) 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II/I Category I/II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 2,701 lb 3,500 lb Lift Control Type Position control with mechanical draft control Mechanical draft control with upper-link draft sensing; Lift-O-Matic rear hitch control ▶ Transmission & DrivetrainTransmission Type 8x8 synchronized shuttle 12x12 hydraulic power shuttle No. of Speeds 8F/8R 12F/12R Max Travel Speed (Forward) Not Published 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dry, 11 in diameter, organic plate 11 in single dry disc Differential Lock & Limited Slip Options Mechanical rear differential lock (foot pedal); 4WD front axle with limited slip and front differential lock Mechanically engaged rear differential lock; limited-slip 4WD front axle with electro-hydraulic push-button engagement ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Hydrostatic power steering Brakes Individual mechanically actuated wet disc Hydraulic-assist wet brakes Seat Suspension & Adjustability Deluxe contoured suspension seat, adjusts to operator height Cloth air-suspension seat with fold-back instructor seat Front Axle Type 4WD: limited-slip front axle with front differential lock, mechanical engagement 4WD (MFD) limited-slip front axle, electro-hydraulic engagement Front Axle Rating Not Published 6,500 lb dynamic capacity Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 67.5 in (shipping width) Not Published Wheelbase ROPS 4WD: 77.6 in 83.6 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS ROPS 4WD: 97.6 in Not Applicable Height to Top of ROPS (folded) Not Published Not Applicable Height to Top of Cab Model Not Applicable 100.2 in Overall Length ROPS 4WD: 134 in 154.1 in ▶ WeightTractor Weight (Base) ROPS 2WD: 4,442 lb (shipping weight); ROPS 4WD: 5,059 lb (shipping weight) 6,800 lb (cab, 4WD) Weight with ROPS and Loader Not Published Not Applicable Weight with Cab and Loader Not Applicable Not Published ▶ Tire OptionsTire Size & Options R1 agricultural, R3 turf, R4 industrial R1 agricultural (11.2x24 / 16.9x30 standard, R1W radials optional), R4 industrial (12.5/80-18 / 19.5L-24) R1 Agricultural - Front Not Published 11.2x24 R1, 6 ply R1 Agricultural - Rear 14.9x28 R1 16.9x30 R1, 6 ply R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12.5/80-18 R4, 10 ply R4 Industrial - Rear 18.4x24 R4 19.5L-24 R4, 10 ply ▶ Loader & AttachmentsQuick Attach Loader System 600TL Series quick-attach loader (611TL, 621TL, 616TL, 626TL) 72 in bucket with SSL (skid steer) or Euro-style quick attach Loader Model 611TL, 616TL, 621TL, 626TL (611TL and 621TL non self-leveling; 616TL and 626TL mechanical self-leveling) 550LU (non self-leveling); 555LU (mechanical self-leveling) Loader Lift Height 611TL: 112 in; 616TL: 115 in; 621TL: 119 in; 626TL: 122 in 550LU: 131.3 in; 555LU: 130.0 in (at pivot pin) Loader Lift Capacity (Full Height) Not Published 550LU: 2,425 lb; 555LU: 3,153 lb (at max height, 31.5 in ahead of bucket pivot pin) Loader Breakout Force 611TL: 2,998 lb; 616TL: 3,130 lb; 621TL: 3,086 lb; 626TL: 3,527 lb (at 31.5 in in front of pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
