▶ EngineEngine Manufacturer FPT John Deere Engine Model S8000 PowerTech 3029 (2.9L) EWR Engine Type Turbocharged 3-cylinder diesel Diesel, turbocharged No. of Cylinders 3 3 Displacement 179 in³ 179 in³ Rated Engine Speed 2300 rpm 2100 rpm Engine Power (Gross) 74 hp 73.7 hp PTO Power 60 hp PR/TSS OOS: 57 hp; PR/TSS Cab: 55 hp; eHydro: 51.4 hp Engine Emissions Constraints Tier 4B Final Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner PowerCore dry air cleaner Dry type with safety element Fuel System Bosch electronic high-pressure common rail Electronically controlled, high-pressure common rail Alternator 120 A 110 A ▶ HydraulicsPump Type Dual gear pumps PR/TSS: tandem gear pump (implement + steering); eHydro: three pumps Implement Flow 12.6 gpm 11.4 gpm Steering Flow 7.6 gpm 6.8 gpm Total Hydraulic Flow 20.2 gpm PR/TSS: 18.2 gpm; eHydro: 29.6 gpm Overall Hydraulic Pump Flow 20.2 gpm PR/TSS: 18.2 gpm; eHydro: 29.6 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published 11.4 gpm at a single rear SCV No. of Standard Remote Valves 2 1 No. of Optional Remote Valves 1 2 ▶ Fluid CapacityFuel Tank Capacity 21.7 gal OOS: 19 gal; Cab: 21 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published 9.0 qt (with filter) Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side ▶ PTO & HitchPTO Type Fully independent, hydraulic wet clutch Independent PTO Rear 540 rpm (540/540E optional) 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I/II Category II, convertible to I Hitch Lift Capacity Not Published 3,968 lb @ hitch points Hitch Lift Capacity (at 24”) 3,500 lb 3,192 lb Lift Control Type Mechanical draft control (upper-link draft sensing) Position control, draft control, adjustable rate of drop ▶ Transmission & DrivetrainTransmission Type 12x12 hydraulic power shuttle SyncShuttle (standard); PowrReverser or eHydro (optional) No. of Speeds 12F/12R 9F/3R (SyncShuttle); 12F/12R (PowrReverser) Max Travel Speed (Forward) 25 mph 15.5 mph (SyncShuttle) Max Travel Speed (Reverse) Not Published Not Published Clutch 11 in single dry disc SyncShuttle: dry; PowrReverser: wet; eHydro: hydrostatic Differential Lock & Limited Slip Options Mechanically engaged rear differential lock; limited-slip 4WD front axle with electro-hydraulic push-button engagement Mechanical, rear ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulic-assist wet brakes Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Cab: cloth air-suspension seat with fold-back instructor seat; ROPS: mechanical vinyl suspension seat Not Published Front Axle Type 4WD (MFD) limited-slip front axle, electro-hydraulic engagement 2WD or MFWD Front Axle Rating 6,500 lb dynamic capacity Not Published Drawbar Capacity Not Published Adjustable drawbar ▶ Dimensions & ManeuverabilityOverall Width Not Published Not Published Wheelbase 83.6 in 80.7 in Ground Clearance Not Published 2WD: 18.8 in; MFWD: 13.4 in Min. Turn Radius without Brakes Not Published 11.5 ft (2WD); 15.3 ft (MFWD) Height to Top of ROPS 99.8 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.2 in Not Published Overall Length 154.1 in 144.5 in ▶ WeightTractor Weight (Base) ROPS: 6,250 lb; Cab: 6,800 lb OOS 2WD: 5,555 lb; OOS MFWD: 6,029 lb; Cab 2WD: 6,590 lb; Cab MFWD: 6,812 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural (11.2x24 / 16.9x30 standard, R1W radials optional), R4 industrial (12.5/80-18 / 19.5L-24) Not Published R1 Agricultural - Front 11.2x24 R1, 6 ply MFWD: 11.2-24; 12.4-24 R1 Agricultural - Rear 16.9x30 R1, 6 ply 16.9-28 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5/80-18 R4, 10 ply Not Published R4 Industrial - Rear 19.5L-24 R4, 10 ply Not Published ▶ Loader & AttachmentsQuick Attach Loader System 72 in bucket with SSL (skid steer) or Euro-style quick attach 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader Loader Model 550LU (non self-leveling); 555LU (mechanical self-leveling) 500E, 500M or 520M Loader Lift Height 550LU: 131.3 in; 555LU: 130.0 in (at pivot pin) 500M: 124 in Loader Lift Capacity (Full Height) 550LU: 2,425 lb; 555LU: 3,153 lb (at max height, 31.5 in ahead of bucket pivot pin) 500M: 3,225 lb (at pivot, full height) Loader Breakout Force Not Published 500M: 4,354 lb (at pivot) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
