▶ EngineAir Cleaner Dry Dual Element Dry Engine Type 4Cycle, Line, Water-cooled Diesel turbo charged Vertical Water-cooled 4 Cycle Diesel Engine Displacement 127.6 in³ 114.7 in³ Engine Model 4TNV86CT-KKTF n/a No. of Cylinders 4 3 Rated Engine Speed 2800 rpm 2600 rpm Engine Manufacturer YANMAR LS Mtron Engine Power (Gross) 55.1 hp @ 800 rpm 55 hp Engine Emissions Constraints Tier 4 EPA & CARB Tier4F, EU Stage IIIB PTO Power n/a 46.7 hp Alternator n/a 70 A, 12 V Fuel System n/a CRDI Cooling System Type n/a Water-cooled ▶ WeightWeight with ROPS and Loader 4,233 lbs Not Published Weight with Cab and Loader n/a Not Published ▶ HydraulicsTotal Hydraulic Flow 14.5 gpm 54.9 lpm 13.0 gpm Hydraulic System Type Independent fully "Live" hydraulic pump and separate reservoir. Position controls with isolating & response control Open center Rear Remote Hydraulic Flow 9.5 gpm 36.0 lpm Not Published Overall Hydraulic Pump Flow 9.5 gpm 36.0 lpm 13.0 gpm No. of Standard Remote Valves 2 2 pairs (Front) Pump Type n/a Gear pump Steering Flow n/a 4.8 gpm Implement Flow n/a 8.2 gpm No. of Optional Remote Valves n/a 1/2 pairs (Rear, Option) ▶ PTO & HitchPTO Rear 540 540 rpm (Standard) Hitch Lift Capacity 3,314 lbs 2,910 lb PTO Type n/a Independent Lift Control Type n/a Position control Mid-PTO Availability n/a Not Published Category, 3-Point Hitch n/a Category I Hitch Lift Capacity (at 24”) n/a 2,425 lb ▶ Fluid CapacityCrankcase Capacity 5.3ℓ (1.4US gal) Not Published Front Axle Fluid Capacity 10ℓ (2.64 US gal) Not Published Transmission / Hydraulic System Capacity 35ℓ (9.24 US gal) Not Published Coolant Capacity n/a Not Published Fuel Tank Capacity n/a 13.7 gal ▶ Transmission & DrivetrainMax Travel Speed (Forward) 19.1 mph (19.06 m/h) Not Published Max Travel Speed (Reverse) 16.1 mph (16.07 m/h) Not Published Clutch n/a E: Dry Single; HE: Not Applicable No. of Speeds n/a E: F8×R8; HE: 3 ranges Transmission Type n/a E: Synchro Shuttle/Constant Mesh; HE: HST Differential Lock & Limited Slip Options n/a Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsSteering Hydraulic power steering Hydrostatic Power Steering Brakes n/a Wet, Multi-disc Frame Type n/a Not Published Front Axle Type n/a Not Published Drawbar Capacity n/a Not Published Front Axle Rating n/a Not Published Seat Suspension & Adjustability n/a Not Published ▶ Dimensions & ManeuverabilityOverall Width 63.4 in (63.4") 68 in Ground Clearance 14.6 in (14.6") Not Published Height to Top of Cab Model 108.9 in (108.9") Not Applicable Overall Length with 3-Point Hitch 137.8 in (137.8") 125 in Wheelbase n/a 74.8 in Height to Top of ROPS n/a 100 in Height to Top of ROPS (folded) n/a Not Published Min. Turn Radius without Brakes n/a Not Published ▶ WarrantyWarranty Length & Coverage n/a 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty ▶ Tire OptionsR3 Turf - Rear n/a 44X18.00-20 R3 Turf - Front n/a 29X12.50-15 Tire Size & Options n/a R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear n/a 4.6 gal-24 R4 Industrial - Front n/a 10.0-16.5 R1 Agricultural - Rear n/a 14.9-24 R1 Agricultural - Front n/a 9.5-16 ▶ Loader & AttachmentsLoader Lift Height n/a LL4105: 92.9 in; LL4002: 103.8 in Loader Breakout Force n/a LL4105: 3,419 lb; LL4002: Not Published Quick Attach Loader System n/a LL4105, LL4002: Skid Steer Quick Attach Bucket System (2-lever skid steer coupler) Loader Lift Capacity (Full Height) n/a LL4105: 2,550 lb; LL4002: 3,093 lb ▶ ITC Company AccessoriesAccessories that fit None tagged yet
