▶ EnginePTO Power 18.1 hp 18.8 hp Alternator 40 A, 12 V 40 A, 12 V Air Cleaner Not Published Dry Element Engine Type 3-cylinder, naturally aspirated diesel Water cooled 4 cycle, 3 cylinder diesel Fuel System Diesel Indirect Injection Displacement 77.2 in³ 77.3 in³ No. of Cylinders 3 3 Rated Engine Speed 3200 rpm 3000 rpm Cooling System Type Liquid cooled Water cooled, Forced circulation Engine Manufacturer YANMAR YANMAR Engine Power (Gross) 23.9 hp 23.9 hp Engine Emissions Constraints Tier 4 Not Published ▶ WeightWeight with ROPS and Loader 1,715 lb 1,610 lb Weight with Cab and Loader Not Applicable Not Applicable Tractor Weight (Base) n/a 1,656 lb ▶ WarrantyWarranty Length & Coverage Tractor (private individual usage): 24 months or 2,000 hours; Powertrain (engine and transmission core components): 10 years or 3,000 hours; Attachments: 1-year limited warranty Engine & Powertrain: 84 months (7 years) or 2,000 hours ▶ HydraulicsPump Type open center Gear pump Steering Flow 3.7 US gal/min 2.8 gpm Implement Flow 4.3 US gal/min 4.2 gpm Total Hydraulic Flow 8.0 gpm (implement + steering combined) 7.0 gpm Hydraulic System Type Position Control, Open Center Power Assisted Hydro-Static Rear Remote Hydraulic Flow 4.3 gpm (implement circuit); 3.7 gpm dedicated to steering Not Applicable Overall Hydraulic Pump Flow 8 gpm 6.95 gpm No. of Optional Remote Valves Not Published Not Published No. of Standard Remote Valves 2 (dual rear remote valves, standard) Not Applicable System Operating Pressure n/a 341.7 lbf/cm2 ▶ PTO & HitchPTO Rear 1.4 in OD, 6 Splines; Independent; 554 RPM @ 3,200 Engine RPM 540 rpm @ 2,893 engine rpm PTO Type Hydraulic Clutch, Independent Independent Lift Control Type Position Control Position control Hitch Lift Capacity 1,209 lb 1,323 lb Mid-PTO Availability SAE16/32, 15 Splines; Independent; 2,057 RPM @ 3,200 Engine RPM Yes (2,000 rpm @ 2,875 engine rpm) Category, 3-Point Hitch Limited Category 1 Category I (N) Hitch Lift Capacity (at 24”) 1,209 lb 1,101 lb @ 24 in behind lift point ▶ Tire OptionsR3 Turf - Rear 33x12.5-16.5 4PR 29X12.5-15 R3 Turf - Front 23x8.50-12 4PR 20X8-10 Tire Size & Options R3 Turf or R4 Industrial standard; R4 front: 23x8.50-12 4PR, R4 rear: 12-16.5 10PR R1 (Ag) / R3 (Turf) / R4 (Industrial) R4 Industrial - Rear 12-16.5 10PR 27X12-16.5 R4 Industrial - Front 23x8.50-12 4PR 23X8.5-12 R1 Agricultural - Rear Not Applicable 9.5-16 R1 Agricultural - Front Not Applicable 6-12 ▶ Fluid CapacityCoolant Capacity 3.0 US qt 3.8 ℓ (1 US gal) Crankcase Capacity 3.6 US qt 2.7 ℓ (0.71 US gal) Fuel Tank Capacity 6.1 US gal 22 ℓ (5.81 US gal) Front Axle Fluid Capacity 3.7 US gal 0.85 gal Transmission / Hydraulic System Capacity 4.1 US gal 3.83 gal ▶ Loader & AttachmentsLoader Lift Height 79 in. to pivot pin; 58 in. under level bucket 75.5 in (pivot pin) Loader Breakout Force 2,090 lb at pivot pin 1,531 lb (pivot pin, ground level) Quick Attach Loader System Quick Attach SSQA Loader Lift Capacity (Full Height) 1,200 lb at pivot pin 992 lb (pivot pin) ▶ Transmission & DrivetrainClutch Not Applicable No No. of Speeds 2 ranges 2 range (Low/High) Transmission Type Hydrostatic Transmission, Dual Range Speeds Hydraulic + Mechanical H/L with Sliding-mesh MFWD(4WD) Max Travel Speed (Forward) Low: 0-5.9 mph (0-5.8 mph), High: 0-12.3 mph (0-12.2 mph) 10.5 mph (H range, Ag tires) Max Travel Speed (Reverse) Low: 0-4.1 mph (0-4.1 mph), High: 0-8.5 mph (0-8.5 mph) Not Published Differential Lock & Limited Slip Options Differential Lock Differential lock ▶ Chassis, Steering & ControlsBrakes Wet Disk Wet disc, foot-operated Steering Hydrostatic Power Power steering (hydrostatic) Frame Type Full Frame Chassis Sub-compact tractor; selectable 4WD Front Axle Type Yanmar-designed 4WD front axle with oscillation Not Published Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability High-back seat with armrests on spring suspension platform; fore-and-aft adjustment; swivels for backhoe operation Not Published ▶ Dimensions & ManeuverabilityWheelbase 63.0 in. 66.1 in Overall Width 54.6 in. with R4 Tires 50.8 in Ground Clearance 8.5 in. with R4 Tires 8.2 in Height to Top of ROPS 85.8 in. with R4 Tires 89.7 in Height to Top of Cab Model Not Applicable Not Applicable Height to Top of ROPS (folded) 70.4 in. with Folded ROPS, R4 Tires, Top of Steering Wheel Not Published Min. Turn Radius without Brakes 8.5 ft. (2.6 m) Not Published Overall Length with 3-Point Hitch 105.8 in. 104.0 in Overall Length n/a 92.5 in
